Description

The 6kW Vertical Industrial Infrared Heater delivers powerful, instant radiant heat for industrial and commercial environments. Using advanced short-wave infrared technology, it heats people and surfaces directly, rather than the air, covering up to 44 m² efficiently.

Designed for single-phase 220–240V operation, this vertical heater features a triple-lamp configuration, ultra-low-glare lamps, and robust IP65-rated aluminium housing, making it ideal for warehouses, factories, logistics areas, sports venues, and large workshops.
The bundle includes the Infresco-T 6kW Timer Controller, providing adjustable timed operation, soft-start lamp protection, and energy-saving occupancy control for maximum efficiency.

Key Features

6kW Vertical Industrial Infrared Heater

• 6 kW Infrared Output – Three vertically mounted lamps deliver rapid, even heat across wide areas.
• Instant Radiant Warmth – Provides immediate heat to people and surfaces without air loss.
• Ultra-Low Glare Technology – Minimises visible light while maximising heat output.
• Single-Phase Connection – Plug-and-play simplicity with no specialist electrical setup.
• Energy-Efficient Design – Reduces energy consumption by up to 90% versus conventional heating.
• IP65-Rated Housing – Weather- and dust-resistant for indoor and semi-outdoor use.
• Flexible Mounting Options – Wall, ceiling, or angled vertical installation for optimal coverage.
• Minimal Maintenance – Solid-state infrared technology ensures long operational life.
• Smart Zoning Compatible – Integrates with intelligent controllers to reduce energy wastage.
• 2-Year Manufacturer Warranty – Backed by Shadow Industrial performance guarantee.

Infresco-T 6kW Controller

• Energy Saving – Activates heating only when required.
• Extended Lamp Life – Soft-start and zero-voltage switching reduce high inrush currents.
• Control Capacity – Controls up to 4 × 1500W lamps efficiently.
• Cost-Effective & Reliable – Low-cost solution for effective heating and lighting control.
• User-Friendly Installation – Simple setup and minimal maintenance.
• Soft-Start/Zero-Voltage Switch-Off – Extends lamp life and ensures safe operation.

Applications

The 6kW Vertical Infrared Heater is ideal for:

• Warehouses and distribution centres
• Manufacturing and assembly areas
• Workshops, garages, and vehicle bays
• Indoor sports halls and gymnasiums
• Agricultural buildings and greenhouses
• Exhibition venues, retail complexes, and zoos
• Outdoor covered loading bays and workspaces

Technical Specifications

6kW Vertical Industrial Infrared Heater

• Model: United Automation 6kW Vertical Infrared Heater
• Voltage: 220–240 V AC
• Phase: Single Phase
• Total Power Output: 6 kW
• Lamp Configuration: 3 × 2 kW ultra-low-glare short-wave infrared lamps
• Current per Phase: 26 A
• Coverage Area: Up to 44 m²
• Ingress Protection: IP65
• Dimensions (W × H × D): 525 × 111 × 422 mm
• Weight: 8.4 kg
• Lamp Length: 382 mm
• Minimum Mounting Height: 3.5 m
• Minimum Ceiling Clearance: 0.25 m
• Minimum Side Clearance: 2 m
• Cable: 1.8 m (UK plug supplied for testing; hard-wire recommended)
• Housing Material: Anodised aluminium
• Warranty: 2 years (heater only; lamp not covered)

Infresco-T 6kW Timer Controller

• Supply Voltage: 230V AC ±10% @ 50/60Hz
• Switching Capacity: 6 kW Max
• Lamp On-Time: Adjustable 1–60 minutes
• Control Circuit Consumption: 20 mA
• Terminals: 6.0 mm² rising clamp
• Operating Temperature: –20°C to +40°C
• Protection Rating: IP65
• Gland Diameter: Max. 2.5 mm²
• Enclosure Dimensions (W × L × H): 130 × 130 × 75 mm
• Functionality: Soft-start and zero-voltage switching
