Description

2x 3kW Vertical Industrial Heater & Infresco-T 6kW Timer Control Bundle

This high-performance bundle combines two 3kW Vertical Industrial Infrared Heaters with the powerful Infresco-T 6kW Timer Controller, creating a complete, energy-optimised heating system for industrial, commercial, and sheltered outdoor environments.

Each 3kW vertical heater delivers immediate, targeted warmth through short-wave infrared technology—directly heating people and objects without wasting energy on air movement. With a combined capability to heat up to 60m², these heaters are ideal for production lines, loading bays, workshops, and logistics areas requiring reliable, controllable radiant heat.

The Infresco-T 6kW controller enhances efficiency by allowing timed operation between 1 and 60 minutes. Its soft-start and zero-voltage switching functions protect lamps from high inrush currents, extending lamp life by up to 30%. Designed for both indoor and outdoor applications, the IP65-rated controller offers simple installation and robust long-term performance.

Together, this bundle provides powerful industrial heating with intelligent energy management—now at 15% off.

Key Features

3kW Vertical Industrial Infrared Heater (x2)

• Instant Heat Delivery: No warm-up time—heat is available immediately.

• Highly Energy Efficient: Achieves up to 90% savings compared to convection heating.

• Ultra-Low Glare Lamps: High heat output with reduced visible light.

• Vertical Dual-Lamp Arrangement: Enhances downward radiant focus and heat distribution.

• IP65 Weather Protection: Dust-tight and water-resistant aluminium housing.

• Versatile Mounting: Wall or ceiling installation; compact footprint for tight spaces.

• Long-Life Components: Solid-state reliability and durable lamp construction.

• Ideal for Heat Zoning: Works seamlessly with controllers like Infresco-T.

• 2-Year Manufacturer Warranty: (lamp excluded).

Infresco-T 6kW Timer Controller

• Energy-Saving Timer Control: Lamp activation adjustable from 1 to 60 minutes.

• Soft-Start Technology: Reduces inrush current to increase lamp lifespan by up to 30%.

• Zero-Voltage Switching: Enhances system efficiency and component protection.

• IP65-Rated Enclosure: Suitable for both outdoor and industrial environments.

• Controls Up to 4 × 1.5kW Lamps (Maximum 6kW): Perfect for dual heater setups.

• User-Friendly Wiring: Simple, low-maintenance installation.

• Cost-Effective: Affordable yet feature-rich heating control solution.

Applications

This dual-heater bundle with a 6kW timer controller is ideal for:

Industrial & Manufacturing

• Warehouses & distribution centres

• Factory production lines

• Assembly areas & workstations

• Machine shops and engineering bays

• Loading docks & dispatch zones

Commercial & Retail

• Garage workshops

• Retail storage areas

• Commercial units and logistics hubs

Hospitality & Outdoor Use

• Smoking shelters

• Patios and covered terraces

• Outdoor dining & hospitality zones

Public & Specialist Environments

• Churches and halls

• Indoor sports facilities

• Agricultural structures & greenhouses

Perfect for areas requiring controlled, efficient, and reliable radiant heating.

Technical Specifications

3kW Vertical Industrial Infrared Heater (#903676)

• Voltage: 220–240V AC

• Phase: Single

• Power Output: 3kW (2 × 1.5kW lamps)

• Current per Phase: 13A

• Coverage Area: Up to 30m² per heater

• Ingress Protection: IP65

• Dimensions (W × H × D): 390 × 111 × 422 mm

• Weight: 6.1 kg

• Lamp Type: Ultra-low glare infrared (382 mm)

• Cable Length: 1.8m with UK plug (for testing only)

• Min Mounting Height: 2.5 m

• Clearances: 0.19 m ceiling, 1 m side wall

• Construction: Aluminium housing

• Warranty: 2 years (lamp excluded)

Infresco-T 6kW Timer Controller

• Supply Voltage: 230V AC ±10% @ 50/60Hz

• Switching Capacity: 6kW max.

• Lamp On-Time: Adjustable 1–60 minutes

• Control Circuit Consumption: 20mA

• Terminal Capacity: 6.0mm² rising clamp

• Operating Temperature: -20°C to 40°C

• Protection: IP65

• Cable Gland: Max 2.5mm²

• Dimensions (W × L × H): 130 × 130 × 75 mm

• Technology: Soft-start, zero-voltage switching
