Infresco-S Protect Soft-Start 6kW: High-Capacity Infrared Lamp Life Extender

The Infresco-S Protect Soft-Start 6kW is a high-capacity, microcontroller-based controller designed to protect infrared heater lamps and optimise energy usage in demanding commercial and industrial environments. Specifically engineered for use with quartz infrared halogen lamps and other resistive heating or lighting loads, this unit focuses on reducing electrical stress caused by high inrush currents at switch-on.

Incorporating advanced soft-start technology and zero-voltage switch-off, the Infresco-S 6kW gradually applies power to connected heaters, significantly reducing inrush current and thermal shock. This controlled start-up can extend lamp life by up to 30%, while also reducing strain on the mains supply. With the ability to manage up to four 1.5kW lamps, robust IP65 protection, and multiple cable entry points for straightforward wiring, the Infresco-S 6kW provides a reliable, low-maintenance solution for both indoor and outdoor heating applications.

Key Features

• Extended Lamp Life – Soft-start and zero-voltage switch-off reduce inrush current and electrical stress, extending heater lamp life by up to 30%.

• High Load Capacity – Controls up to 6kW, suitable for up to four 1.5kW lamps.

• Energy Efficient Operation – Minimises surge currents to protect heater elements and improve system efficiency.

• Soft-Start Function – Smooth, controlled power-up prevents thermal and electrical shock.

• Zero-Voltage Switching – Enhances safety, reduces mains disturbance, and improves reliability.

• Easy Installation – Designed with multiple cable entry points for flexible and simple wiring.

• Durable IP65 Enclosure – Provides protection against dust and water for indoor and outdoor use.

• Microcontroller-Based Design – Ensures accurate, consistent performance with minimal maintenance.

Applications

The Infresco-S Protect Soft-Start 6kW is ideal for a wide range of residential, commercial, and industrial applications, including:

• Patio Heating

• Smoking Shelters

• Restaurants & Outdoor Dining Areas

• Warehouses

• Workshops

• Garden & Landscape Lighting

• Livery Stables

This controller is particularly suited to installations where lamp longevity, reduced maintenance, and protection against electrical surges are critical.

Technical Specifications

• Mains Voltage: 230V AC ±10%, 50/60Hz

• Maximum Operating Current: 25A

• Control Circuit Power Consumption: 50mA

• Operating Temperature (PCB): -40°C to +30°C

• Terminal Type: Rising clamp

• Maximum Cable Entry Size: 6mm

• Lamp Installation: Must be fitted in parallel

• Maximum Lamp Load: 4 × 1.5kW

• Remote Switch Type: Latching

• Ingress Protection Rating: IP65

• Gland Diameter (Fitted): 4mm

• Maximum Cable Entry (Lamp Wiring): 2.5mm²
