VentGuard Plus c/w Integral Current Monitors

Description

The VentGuard Plus is a cost-effective ventilation interlock system designed for compliance with BS6173:2009 and IGEM/UP/19 standards. Equipped with integral current monitors for both intake and extract fans, this system ensures that your ventilation setup operates efficiently and safely. While it includes built-in fan current monitoring, it can also be used with Air DP switches for additional flexibility.

Designed with user convenience in mind, the VentGuard Plus features dedicated interfaces and LED indicators for both intake and extract fans, providing clear visual feedback on ventilation performance. The system is engineered to prevent unnecessary shutdowns by delaying gas supply cutoff for 30 seconds, ensuring that brief ventilation interruptions don’t cause nuisance tripping.

Key Features:

• Clear LED Indication: Easily monitor the status of your ventilation system with dedicated LEDs for intake and extract fans.
• Integral 2-Channel Fan Current Monitor: Built-in monitoring for both intake and extract fans to ensure reliable operation.
• Versatile Interfaces: Supports Intake Fan DP, Extract Fan DP, CO2 Sensors, and Remote Emergency Stop Buttons for comprehensive system integration.
• Mains Rated Status Relay: Allows for external monitoring of system status.
• Built-in Time Delays: Prevents nuisance tripping by delaying gas supply shutdown during brief ventilation interruptions.
• 5-Year Warranty by Flamefast: Confidence in durability and performance with a long-term warranty.
• UK Manufactured: High-quality, locally manufactured product.

Dimensions:

• Height: 180 mm
• Width: 130 mm
• Depth: 60 mm (65 mm including Stop & Key Switch)

Technical Specifications:

• Power Supply: 100 – 240 VAC 50/60Hz for reliable operation across a wide voltage range.
• Power Consumption: 50W Max
• Fan Current Rating: 0.2 – 15A @ 230V, accommodating a variety of fan sizes.
• Power Output: Gas Solenoid, Switched Mains for dependable control.
• IP Rating: IP65, providing robust protection against dust and water.
• Approval: CE and UKCA certified for compliance with safety and performance standards.

External Device Interfaces:

• Valve Status: SPDT – 5A @ 240V Max
• CO2 Sensor: 24V Signal to monitor external VFC
• Intake Fan: 24V Signal to monitor external VFC
• Extract Fan: 24V Signal to monitor external VFC
• Remote Stop: 24V Signal to monitor external VFC

The VentGuard Plus offers a reliable, compliant, and versatile solution for ensuring safe and effective ventilation in a variety of environments. Its integrated monitoring features, combined with robust safety mechanisms, make it an ideal choice for maintaining safe gas and ventilation operations.
