Description
The VAC2-2E-RFI Fan Speed Control Module is a compact, efficient solution designed to regulate fan speed in a wide variety of heating and ventilation systems. Its streamlined installation process requires only two in-line wiring connections to the mains supply, making it an ideal choice for quick and easy setup. The module’s fan speed is adjustable via an integrated cermet, providing precise control for your application. Additionally, an internal RC snubber network enhances its performance with inductive fan loads up to 2A, ensuring smooth and reliable operation.
Key Applications:
The VAC2-2E-RFI is suitable for controlling most mains AC fans and other inductive loads, making it versatile for use in heating, ventilation, and air conditioning (HVAC) systems across industrial and commercial settings.
Key Features:
- Compact Design: Space-saving and easy to integrate into existing systems.
- Solid-State Reliability: Durable construction for long-lasting performance without mechanical wear.
- Adjustable Speed Output: Fine-tune fan speed to match specific requirements.
- Simple Wiring: Easy installation with minimal wiring complexity.
- Internal RFI Filter: Reduces electromagnetic interference, ensuring stable and efficient operation.
Technical Specifications:
- AC Line Voltage: 230V ± 10% @ 50/60 Hz
- Minimum Operating Current: 200mA
- Peak One Cycle Surge (10ms): 10A
- Unit Limiting RMS Current: 2A
- Isolation Voltage: 2kV
- Maximum Peak Voltage: 600V AC
- Leakage Current: 10mA
- Maximum Operating Temperature: 65°C
- Storage Temperature: 0 – 65°C
The VAC2-2E-RFI Fan Speed Control Module is the perfect choice for managing fan speed in HVAC applications, combining ease of installation, precise control, and robust performance in a compact, reliable package.
