Infresco 1.5kW 4 Step Power IR Regulator – Manual Control

Description

The INFRESCO-VR-1.5kW controller is designed for precise, variable control of mains-driven loads, specifically Quartz Halogen Infrared heat lamps, up to a total of 1.5kW. This advanced microcontroller-based unit features a ‘soft-start’ function that gradually switches on the lamp, eliminating the initial high inrush current and potentially extending lamp life by up to 30%.

With easy-to-use up and down push-buttons, users can select output levels, indicated by a high-intensity LED that shows when the controller is regulating power to the lamp load. Additionally, a built-in relay override function ensures that at maximum power (100%), the relay bypasses the power devices to minimise heat dissipation, maintaining a lower operating temperature.

The INFRESCO-VR-1.5kW controller is simple to install, low maintenance and offers robust performance for a variety of settings.

Key Features

• Simple Wall Mounting: Easy to install on any wall surface.
• IP55 Protection: Suitable for outdoor installation with dust and water jet protection.
• Soft-Start Function: Gradually switches on the lamp to extend lamp life.
• Simple In-Line Wiring: Connect using 3-core cables for straightforward setup.
• Pre-Selected Heat Output Levels: Choose from multiple heat settings for optimal comfort.
• Power Output Indication: High-intensity LED shows when power is being regulated.
• Integral EMC Filter Suppression: Reduces electromagnetic interference.
• Relay Override at Maximum Output: Minimises heat dissipation at full power.

Applications

Ideal for various environments, including:

• Pub patio areas
• Smoking shelters
• Restaurants
• Warehouses
• Workshops

Technical Specifications

• Supply Voltage: 230V AC ±10%
• Supply Frequency: 50Hz
• Load Rating (Maximum): 6.5A (1.5kW @ 230V AC & 25°C ambient)
• Output Levels: Off, Low, Medium, High & Full Power
• Fusing or MCB Rating (External): 13A (Brown) mains fuse or 16A domestic MCB
• IP Rating: IP55 – Dust protection; protected against water jets
• Operating Temperature: -20°C to 50°C
• Maximum Ambient Temperature: 30°C
• Fixings: 4 x 3.5Ø holes (on 97 x 82mm centres)
• Supply & Load Cable (Recommended): 1.0mm² 400V AC (minimum rating)
• Terminal Cable Ratings: 2.5mm²
• Terminal Torque Settings (Maximum): 0.5 Nm
• Weight: 500g
• Power Consumption (Maximum): 70mA
• Isolation Voltage: 2500V RMS

The INFRESCO-VR-1.5kW controller is the perfect solution for efficient and effective control of infrared heat lamps, ensuring energy savings, extended lamp life, and optimal performance in a variety of settings.
