The CSR-604A is a compact 6A Power Regulator Chip designed for smooth, single-phase AC load control. Delivering high-precision low-hysteresis phase-angle regulation for 110V and 230V systems, this 3-pin chip offers 99% power efficiency. It is a cost-effective, reliable solution for regulating small industrial ovens, catering heat lamps, and motor-driven commercial appliances.
6A, 230V – A Series
£25.00 ex. VAT
| 1-4 | 5-9 | 10-19 | 20+ |
| £25.00 | £23.75 | £22.56 | £21.44 |
The CSR-604A Compact Power Regulator Chip is a compact and reliable solution designed for precise control of single-phase mains-driven loads up to 6A. Built for integration into commercial and industrial equipment, this versatile regulator chip allows smooth and fully adjustable voltage control when used with a variable resistance (potentiometer).
Using phase-angle control, the CSR-604A enables continuous adjustment of the output voltage from zero to maximum, ensuring accurate and efficient power regulation. Its compact design makes it ideal for applications where space is limited but reliable AC power control is essential.
The CSR series provides low hysteresis voltage regulation, ensuring stable performance with minimal fluctuations. Combined with simple 3-pin installation and flexible mounting options, the CSR-604A is easy to integrate into both new equipment designs and retrofit systems.
Whether used in catering equipment, industrial heating systems, or manufacturing machinery, the CSR-604A power regulator chip delivers dependable performance and efficient power management.
6A Load Control Capability
Designed to regulate single-phase AC loads up to 6 amps.
Fully Adjustable Voltage Output
Allows smooth control from zero to maximum output voltage using a potentiometer.
Compact Integrated Design
Small footprint ideal for embedded power control systems.
Multiple Current Ratings Available
CSR series available in 6A, 10A, and 15A versions.
Simple 3-Pin Installation
Quick and straightforward wiring simplifies installation.
Low Hysteresis Regulation
Ensures stable and accurate voltage control.
Flexible Mounting Options
Suitable for various equipment designs and installation configurations.
Cost-Effective Power Regulation
Provides high performance and reliability at an affordable cost.
Precise phase-angle power control for AC loads
Compact design suitable for integrated equipment
High efficiency with up to 99% power transfer
Reliable performance in commercial and industrial environments
Easy installation and maintenance
The CSR-604A Power Regulator Chip is suitable for a wide range of industrial and commercial applications, including:
Industrial ovens and heating equipment
Fish and chip fryers
Restaurant and hospitality appliances
Quartz lamps and heat lamps
Moulding machines
Industrial dryers
Transformers and motor control
Manufacturing equipment
RMS Maximum On-State Current: 6A
Peak One Cycle Surge Current: 100A
Maximum Off Leakage Current: 2 mA
Maximum Holding Load Current: 30 mA
RMS Input Voltage: 110 / 230V AC ±10% @ 50/60Hz
Repetitive Peak Voltage: 400V
Total Conduction Phase Angle (Typical): 0° to 160°
Controlled Phase Angle (Typical): 30° to 160°
Power Transfer Efficiency: Up to 99%
Tab Surface Operating Range: 0°C to +70°C
Storage Temperature: 0°C to +75°C
Insulation Withstand Capability: 1500V for 1 minute
| TECHNICAL SPECIFICATIONS | |||||||
|---|---|---|---|---|---|---|---|
| Specifications | Unit | CSR | CSR | CSR | CSR | CSR | CSR |
| 604A | 604B | 1004A | 1004B | 1504A | 1504B | ||
| RMS max. On state current | A | 6 | 6 | 10 | 10 | 15 | 15 |
| Peak one cycle surge current | A | 100 | 100 | 120 | 120 | 150 | 150 |
| Maximum off leakage current | mA | 2 | |||||
| Maximum holding load current | mA | 30 | |||||
| RMS input voltage +/- 10% @50/60 Hz | V | 110/230 | |||||
| Repetitive peak voltage | V | 400 | |||||
| Total conduction phase angle (typical) | Degrees | 0 TO 160° | |||||
| Controlled phase angle (typical) | Degrees | 30 TO 160° | |||||
| Power transfer at max. Current (efficiency) | % | 99 | |||||
| Tab surface operating range | °C | 0 to +70 | |||||
| Storage temperature | °C | 0 to +75 | |||||
| Insulation withstand capability | V | 1500 for 1 min. | |||||
| Rated Current | 6A |
|---|---|
| Version | A Series |
| Voltage | 230V |
