Differential Air Pressure Switch

Description

Ensure the efficient operation of your ventilation systems with our Differential Air Pressure Switch. Designed to monitor pressure differentials caused by air movement, these switches are perfect for verifying ventilation performance. When integrated with any GasGuard system, they provide a BS6173:2009 and IGEM/UP/19 compliant interlock, ensuring safety and reliability in your operations.

Differential Air Pressure Switch: Key Features

• Precise Pressure Monitoring: With a range of 20 – 300Pa, this switch allows for accurate monitoring of air pressure differentials.
• Adjustable Set Point: Easily set and adjust the pressure point to meet specific system requirements.
• Comprehensive Duct Kit: Supplied with a 2m hose, 2 pitot tubes, and fixing screws for easy installation.
• Robust Construction: Dimensions of 88mm (height) x 92mm (width) x 52mm (depth) ensure a compact yet durable design.
• Versatile Output: SPDT VFC output rated at 1.5A @ 250V max.
• High Protection Rating: IP54 rated for dust and water protection.
• Certified Quality: Approved with CE and UKCA certifications.

Applications

The Differential Air Pressure Switch is perfect for a variety of applications including:

• Ensuring the correct operation of HVAC and ventilation systems.
• Providing compliant interlock solutions for gas safety systems.
• Monitoring air pressure in industrial and commercial environments.
• Kitchen Interlock with Gas Pressure Proving: Ideal for ensuring the safe and correct operation of kitchen ventilation systems when interfaced with gas pressure proving systems.
• Kitchen Interlock – Non-Pressure Proving: Suitable for general kitchen ventilation applications where gas pressure proving is not required.

Technical Specifications

• VFC Output: SPDT – 1.5A @ 250V Max
• Range: 20 – 300Pa
• IP Rating: IP54
• Approval: CE, UKCA

Dimensions

• Height: 88 mm
• Width: 92 mm
• Depth: 52 mm

Duct Kit Included

The Differential Air Pressure Switch comes with a comprehensive duct kit, including 2 meters of hose, 2 pitot tubes, and fixing screws, making installation straightforward and hassle-free.
